Advantages of FFTtesting S3 Seamless integration into your production process.
Compact & customizable
Energy efficient
Scalability
Extensions and adaptations Modularity
Standalone
Stand-alone measurement applications for long-term monitoring of measurement parameters and internal data storage. no direct visualization required / possible.
Point-to-Point
Measurement application with a second sensor board as a gateway, e.g. to display measurement data on a display device in real time or to save it in an external database.
Network
Several sensor boards form a network that sends measurement data from different areas to a gateway and acts as an interface to a conventional DAQ system, for example.
FFTtesting S3 Technical specifications
FFTtesting S3
Testing that inspires. We look forward to getting in touch with you:
Send us your concept idea, your automation requirements or a description of the process you would like us to support you with. We look forward to presenting our standardized portfolio to you, but also to developing new solutions together with you.
Your FFTtesting contact:
